Description
Materials:
Steel with resistance class 5.8.
Surface:
Low roughness turned surface.
Colour:
Nickel plated ( galvanic treatment).
Alternative treatment:
Black-oxydation:
(change the final letter of the code (H) with the B (W510082.SD0801B)).
Zinc plating:
(change the final letter of the code (H) with the Z (W510082.SD0801Z)).
Handgrip:
Ball knob article I104, in black reinforced polyamide, (RAL 9011). [see pageFAM_I104.
Handgrip fastening:
Push-fit, removable.
Hole:
Female smooth blind bore, (bore tolerance H10).
Central cap:
Grey polyamide cap (RAL 7035 cod. 13).
Alternative cap colours:
For black-oxyde lever version, the central cap will have grey coulor, (RAL 7035 code 13).
Fixing:
For fixing system, or execution of keyway or square holes, please refer to the technical notes attached to the catalogue.
SPECIAL REQUESTS:
It’s possible to supply the levers with customised hole d1, on request and for quantities.
It possible to supply the knob with colours as shown on the colours table page [pageTitoloTabellaColori.
